| Plan Sveise flens NS2525 PN6 |
|
DN
|
Rør Dia.
|
Flens
|
Bolt
|
Vekt Ca
|
||||
|
d1
mm |
D
mm |
b
mm |
k
mm |
antall
|
size
|
d2
mm |
kg/ea
|
|
15
|
21,3 |
80
|
12
|
55
|
4
|
M 10
|
11
|
0,410
|
|
20
|
26,9
|
90
|
14
|
65
|
4
|
M 10
|
11
|
0,600
|
|
25
|
33,7
|
100
|
14
|
75
|
4
|
M 10
|
11
|
0,740
|
|
32
|
42,4
|
120
|
16
|
90
|
4
|
M 12
|
14
|
1,190
|
|
40
|
48,3 |
130
|
16
|
100
|
4
|
M 12
|
14
|
1,390
|
|
50
|
60,3 |
140
|
16
|
110
|
4
|
M 12
|
14
|
1,530
|
|
65
|
76,1
|
160
|
16
|
130
|
4
|
M 12
|
14
|
1,890
|
|
80
|
88,9
|
190
|
18
|
150
|
4
|
M 16
|
18
|
2,980
|
|
100
|
114,3 |
210 |
18
|
170
|
4
|
M 16
|
18
|
3,460
|
|
125
|
139,7 |
240 |
20
|
200
|
8
|
M 16
|
18
|
4,600
|
|
150
|
168,3 |
265
|
20
|
225
|
8
|
M 16
|
18
|
5,220
|
|
200
|
219,1
|
320
|
22
|
280
|
8
|
M 16
|
18
|
7,150
|
|
250
|
273,0
|
375
|
24
|
350
|
12
|
M 16
|
18
|
9,610
|
|
300
|
323,9
|
440
|
24
|
395
|
12
|
M 20
|
22
|
12,6
|
 |
