| STANDARD CONNECTIONS |
| In |
Out |
| G.3/4" ISO 228 |
/ |
| G.1" ISO 228 |
/ |
|
| Homologation |
CE IVˆ (ISPESL - TÜV) |
Overpressure |
10% |
| PN |
100 |
Closing variation |
15% |
| k |
0,80 |
| Opening diameter |
14 |
Setting rang |
0,5 - 80,0 |
|
| VERSION |
MATERIALS |
| Brass |
UNI EN 12164 CW614N
(min -50°C / max 200°C) |
| Brass-Stainless Steel |
UNI EN 12164 CW614N - UNI EN 10088 1.4401
(min -50°C / max 200°C) |
| Stainless Steel |
UNI EN 10088 1.4401
(min -195°C / max 450°C) |
|
| GASKET |
| N.B.R. (Standard) |
-10 / 100 °C |
| E.P.D.M. |
-50 / 150 °C |
| VITON |
-20 / 200 °C |
| SILICONE |
-60 / 200 °C |
| TEFLON |
-100 / 180 °C |
| METALLICA |
-195 / 450 °C |
|
| SPECIAL CONNECTIONS |
| In |
Out |
| R.3/4” ISO 7 |
/ |
| R.1” ISO 7 |
/ |
| 3/4” NPT |
/ |
| 1” NPT |
/ |
| 1” TRI CLAMP |
/ |
| 1”1/2 TRI CLAMP |
/ |
| DN25 DIN 405 – DIN 11851 |
/ |
| DN32 DIN 405 – DIN 11851 |
/ |
| DN25 PN16 / 40 /100 UNI 1” ANSI 150 / 300 / 600 |
/ |
| On request tests can be
made by the most prestigious societies, such as: ISPESL, TÜV,
RINA, Bureau Veritas, ABS and Lloyd Register. |
|
